Specifications
| Wireless Transmission | Technology | LoRaWAN® |
| Frequency | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923 | |
| Tx Power | 16 dBm (868 MHz)/22 dBm (915 MHz)/19 dBm (470 MHz) | |
| Sensitivity | -137 dBm @300bps | |
| Mode | OTAA/ABP Class A | |
| Measurement | Distance | |
| Detection Range | 3 – 450 cm | |
| Detection Accuracy | ± (1+0.3%*S) cm, S=distance | |
| Distance Resolution | 1 mm | |
| Device Position | ||
| Status | Normal/Tilt | |
| Operation | Configuration | NFC Configuration via Mobile App |
| Physical Characteristics | Power Supply | 2 × 3500 mAh ER17505 Li-SOCl2 battery |
| Battery Life* | Up to 10 years (10 min interval + 20 triggers per day) | |
| Operating Temperature | -15°C to +60°C | |
| Relative Humidity | ≤90% (non-condensing) | |
| Ingress Protection | IP67 | |
| Dimension | 111 × 62 × 40 mm (4.37 × 2.44 × 1.57 in) | |
| Weight | 168g | |
| Material & Color | ABS, Black | |
| Installation | On the flat surfaces with screws | |
